1-R1-11 HİDROLİK BSP DÜZ REKOR

BSP SOMUNLU DÜZ HORTUM RAKORLARI
BSP FEMALE STRAIGHT SWIVEL HOSE FITTINGS

HORTUM ÖLÇÜSÜ
HOSE SIZE

SOMUN ÖLÇÜSÜ
NUT SIZE

B

C

ØD

AA

mm

inch

05

3/16

R1/8-28

36

15

3.2

14

05

3/16

R1/4-19

38

17

3.2

17

06

1/4

R1/8-28

40.5

15

4

14

06

1/4

R1/4-19

42.5

17.5

4

17

06

1/4

R3/8-19

45

20

4

22

06

1/4

R1/2-14

48

23

4

27

08

5/16

R1/4-19

44.5

17.5

5.5

17

08

5/16

R3/8-19

47

20

5.5

22

08

5/16

R1/2-14

50

23

5.5

27

10

3/8

R3/8-19

50

20

7

22

10

3/8

R1/2-14

53

23

7

27

12

1/2

R3/8-19

53.5

20.5

9

22

12

1/2

R1/2-14

56.5

23.5

9

27

12

1/2

R5/8-14

59

27

9

30

12

1/2

R3/4-14

60.5

27.5

9

32

16

5/8

R1/2-14

64.5

24.5

12

27

16

5/8

R5/8-14

67

27

12

30

16

5/8

R3/4-14

67.5

27.5

12

32

16

5/8

R1"-11

74

34

12

41

19

3/4

R3/4-14

72

28

14

32

19

3/4

R1"-11

78

34

14

41

25

1"

R1"-11

88

34

19

41

25

1"

R1"1/4-11

88.5

34.5

19

50

32

1"1/4

R1"1/4-11

95.5

36

25

50

38

1"1/2

R1"1/2-11

111.5

39.5

29

55

50

2"

R2"-11

103.5

43.5

41

70

64

2"1/2

R2"1/2-11

109

49

54

90

76

3"

R3"-11

125

60

63

96
